Wall Lights
The Grove Wallwasher is a low-profile, high-efficiency luminaire designed for general wall lighting. The pedestal easily fastens onto a rectangular mounting base and the fixture’s wiring extends from the pedestal bottom to ensure easy installation.
Download Product Files:
LUMEN OUTPUT (75W)
TO 277 VAC
LUMENS / WATT
| Model: | MF-3161-WL-LED-25 |
| Input Voltage |
120~277VAC |
| Wattage | 25 Watts |
| Lumen Output |
3,000 Lm |
| Certifications |
UL 1598 |
| Model: | MF-3161-WL-LED-50 |
| Input Voltage |
120~277VAC |
| Wattage | 50 Watts |
| Lumen Output |
6,000 Lm |
| Certifications |
UL 1598 |
| Model: | MF-3161-WL-LED-75 |
| Input Voltage |
120~277VAC |
| Wattage | 75 Watts |
| Lumen Output |
9,000 Lm |
| Certifications |
UL 1598 |
| RF1 | Specular Reflector |
| RF2 | Semispecular Reflector |
| RF3 | Hammertone Reflector |
| PC | Photocontrol |
| H | Specify Stem Height Needed (3″~24″ Available) |
| 3K | 3000K Color Temperature |
| 4K | 4000K Color Temperature |
| 5K | 5000K Color Temperature |
Download Product Files:
PDF | IES | CAD
CONSTRUCTION
The cast aluminum body attaches to the door frame with (2) stainless steel screws. The fixture’s housing is powder-coated inside and outside. Heat sink ribs are cast into the backside of the housing to allow all thermal energy to dissipate into the air. The pedestal easily fastens onto a rectangular mounting base. The fixture’s wiring extends from the pedestal bottom to ensure easy installation. All hardware is stainless steel for corrosion resistance.
LENS:
The lens is clear with UV stabilized and impact-resistant polycarbonate.
LED LIGHT ENGINE:
Our custom LED module utilizes top-of-the-line 3030 (3mm square) LEDs. Each module is tested in-house to ensure proper lumen and color consistency. Each module is laser marked with a bin and manufacturing information for traceability. Our modules use top-quality metal core PCB for increased thermal dissipation.
FINISH
The standard finish is TGIC acrylic powder coat in MagniBronze. Other colors available from the factory on request
LED LIGHT ENGINE:
Our custom LED module utilizes top-of-the-line 3030 (3mm square) LEDs. Each module is tested in-house to ensure proper lumen and color consistency. Each module is laser marked with bin and manufacturing information for traceability. Our modules use top quality metal core PCB for increased thermal dissipation.
FINISH
The standard finish is TGIC acrylic powder coat in MagniBronze. Other colors available from the factory on request
Dimensions:
